Cabinet cover is designed as inclined plane, more comfortable for viewing.
Separate brine cabinet and FRP tank cabinet, brine cabinet cleanable.
User-friendly and intuitive program, easy to operate.
Big salt inlet, convenient to add salt.
Up flow regeneration to save water and salt.
Residual chlorine generator is optional, with salt alarm and sterilization function.
Complete installation kit, quick connect fittings for simple installation.
Groove design on the body, easy to move the product.
| Model | CS12H-0926 | CS12H-0935 | ||
|---|---|---|---|---|
| Control System | BNT-850SE(UF) | |||
| Regeneration Type | Up Flow | |||
Regeneration Mode | Calendar Clock, Meter Immediate, Meter Delayed, Day Override | |||
| Hardness Removal(Gram) | (@ 48 g/L salt dosage) | 480 | 672 | |
(@ 96 g/L salt dosage) | 750 | 1050 | ||
(@ 160 g/L salt dosage) | 900 | 126 | ||
Tank Size | 09x26 | 09x35 | ||
Resin Quantity | 15 L | 21L | ||
Salt Storage Capacity | 28 KG | 45KG | ||
Rated Service Flow Rate | 20 L/M | 28 L/M | ||
Back Wash Flow Rate | 9 L/M | |||
Water Used Per Regeneration(@ 96 g/L salt dosage) | 80 L | 113L | ||
Product Dimension(D×W×H) | 516×335×901(mm) | 516×335×1132(mm) | ||
Carton Dimension(D×W×H) | 565×355×990(mm) | 565×355×1210(mm) | ||
Shipping Weight | 30 Kg | 42Kg | ||
Electrical Requirements | Input 110V-120V / 220-240V AC 50/60Hz | |||
Output 12V AC 650mA | ||||
Water Supply | Municipal | |||
Operating Temperature | 4～43 ℃ | |||
Operating Pressure | 0.21～0.86 Mpa | |||
Notes: The data of system performance is only for reference, it may vary from different water quality and application. | ||||
