Separate salt brine cabinet and tank cabinet design, easy to clean the brine tank.
Compact body design to save space.
Humanized designed handle to easily move the machine.
Multiple languages for operation.
Core components made in house, better quality control.
Time saving quick connect fittings on bypass, drain and brine line.
Brine valve with safety float to provide extra overflow protection.
| Model | CS10H-Twin Cabinet-Slide | CS10H-Twin Cabinet-Transparent | ||
|---|---|---|---|---|
| Control System | BNT-850F | BNT-1650F | ||
| Regeneration Type | Down Flow | |||
Regeneration Mode | Meter Immediate, Meter Delayed Day Override, Vacation | Meter Immediate, Meter Delayed Day Override, Calendar Clock | ||
| Hardness Removal(Gram) | (@ 48 g/L salt dosage) | 801 | ||
(@ 96 g/L salt dosage) | 1259 | |||
(@ 160 g/L salt dosage) | 1517 | |||
Tank Size | 10x35 | |||
Resin Type | 25 L | |||
Salt Storage Capacity | 46 Kg | |||
Rated Service Flow Rate | 33 L/M | |||
Back Wash Flow Rate | 9 L/M | |||
Water Used Per Regeneration (@ 96 g/L salt dosage) | 127 L | |||
| Carton Size(mm) | 545x360x1170 | 545x360x1200 | ||
Shipping Weight | 47 Kg | 46 Kg | ||
Container Capacity(40" HQ) | 396 pcs | 264 pcs | ||
Plumbing Connections | 3/4” or 1” Fittings Available | |||
Electrical Requirements | Input 110V-120V / 220-240V AC 50/60 Hz | |||
Output 12V AC 650mA | ||||
| Electrical Requirements | Input 110V-120V / 220-240V AC 50/60 Hz | |||
Water Supply | Municipal | |||
Operating Temperature | 4～43 ℃ | |||
Operating Pressure | 0.21～0.86 Mpa | |||
Notes: The data of system performance is only for reference, it may vary from different water quality and application. | ||||
