Brine valve with safety float and provide extra overflow protection.
Automatically detect granular salt volume in brine tank, reminds user to add more salt.
Smart Clean technology will have system flush the water and media in tank automatically during your vacation time.
Residual chlorine generator is optional, thus killing the bacteria or other relevant microbes that affect the water quality in the resin tank.
| Model | CS18H-1015 | CS18H-1035 | CS18H-1044 | CS18H-1135 | CS18H-1144 | |
|---|---|---|---|---|---|---|
|
Control System |
BNT-850SE(UF) Control Valve |
|||||
| Regeneration Type |
UP Flow |
|||||
| Regeneration Mode |
Days,Calendar Weekdays,Meter Immediate,Meter Delay, MD Days Override,MI Days Override |
|||||
| Standard Capacity (96g/l) |
(@ 48 g/L salt dosage) |
309 |
781 |
980 |
963 |
1198 |
|
(@ 96 g/L salt dosage) |
512 | 1590 | 2014 | 1961 | 2438 | |
|
(@ 192 g/L salt dosage) |
669 |
2306 | 2920 | 2844 | 3536 | |
| Tank Size |
10x15 |
10x135 |
10x144 |
11x35 |
11x44 |
|
| Resin Quantity(L) | 12 | 30 | 38 | 37 | 46 | |
| Salt Storage Capacity(Kg) | 15 | 56 | 75 | 51 | 68 | |
|
Rated Service Flow(m³/H) |
1.0 |
2.0 | 2.0 | 2.4 | 2.4 | |
| Back Wash Flow Rate(L/M) | 7.5 | 9 | 9 | 11.4 | 11.4 | |
|
Water Used Per Regeneration(L) (@ 96 g/L salt dosage) |
42 | 118 |
156 |
170 | 225 | |
|
Product Dimension(D×W×H mm) |
435x335x550 | 435x335x1060 | 435x335x1290 | 435x335x1060 | 435x335x1290 | |
|
Carton Size(D×W×H mm) |
520x415x690 | 520x415x1200 | 520x415x1430 | 520x415x1200 | 520x415x1430 | |
| Container Capacity(40" HQ, pcs) | 460 |
230 |
108 |
230 |
108 |
|
| Plumbing Connections |
3/4” or 1” Fittings Available |
|||||
|
Electrical Requirements |
Input 110V-120V / 220-240V AC 50/60 Hz |
|||||
| Output 12V AC 650mA | ||||||
| Water Supply | Municipal | |||||
| Water Temperature(℃ ) | 4 ～ 43 | |||||
| Operating Pressure(MPa) | 0.21～ 0.86 | |||||
|
Notes: 1. The data of softener performance is only for reference, it may vary from different water qualities and applications. 2. Rated Service Flow is based on NSF/ANSI Standard 44. |
||||||
