Compact body design to save space.
Humanized designed handle to easily move the machine.
Multiple languages for operation.
Core components made in house, better quality control.
Exclusive NSF certified electronic control valve with reliable piston, seal and spacer technology.
Time saving quick connect fittings on bypass, drain and brine line.
Brine valve with safety float to provide extra overflow protection.
| Model | CS5H-1017 | CS5H-1035 | CS5H-MO-1017 | CS5H-MO-1035 | |
|---|---|---|---|---|---|
| Control System | BNT-850F | ||||
| Regeneration Type | Down Flow | ||||
| Regeneration Mode | Meter Immediate, Meter Delayed, Meter Override, Vacation | ||||
|
Hardness Removal (Gram) |
(@48 g/L salt dosage) |
401 |
801 | 401 | 801 |
| (@96 g/L salt dosage) | 630 | 1259 | 630 | 1259 | |
| (@160 g/L salt dosage) | 758 | 1517 | 758 | 1517 | |
| Tank Size | 10x17 | 10x35 | 10x17 | 10x35 | |
| Resin Quantity | 12.5L | 25L | 12.5L | 25L | |
| Salt Storage Capacity | 42Kg | 86Kg | 46Kg | 93Kg | |
| Rated Service Flow Rate | 17L/M | 33L/M | 17L/M | 33L/M | |
| Back Wash Flow Rate |
9L/M |
||||
|
Water Used Per REgeneration (@96g/L salt dosage) |
58L | 127L | 58L | 127L | |
| Product Dimension(DxWxH mm) | 490x420x640 | 490x420x1100 | 490x420x640 | 490x420x1100 | |
| Carton Size(mm) | 590x440x690 | 590x440x1160 | 590x440x690 | 590x440x1160 | |
| Shipping Weight | 24Kg | 50Kg | 24Kg | 50Kg | |
| Container Capacity(40" HQ) | 324pcs | 216pcs | 324pcs | 216pcs | |
| Plumbing Connections | 3/4" or 1" Fittings Available | ||||
| Electrical Requirements | Input 110V-120V / 220-240V AC 50/60 Hz | ||||
|
Output 12V AC 650mA |
|||||
| Water Supply | Municipal | ||||
| Water Temperature | 4~43℃ | ||||
| Operating Pressure | 0.21~0.86 Mpa | ||||
| Notes: The data of softener perform ance is only for reference. it may vary from diffrent water qualities and applications. | |||||
